Overview

The Chat API lets you programmatically converse with a published chatbot flow. This is useful for:

Building custom chat UIs outside the web widget
Automated testing of conversation flows
Integrating chatbot capabilities into your own applications

The flow is simple:

Create a session - you get back a session_id (the session starts empty, no greeting yet)
Send messages - pass the session_id with each message, receive the bot's response synchronously. The bot's greeting is returned as the response to your first message
Sessions expire automatically after 30 minutes of inactivity

Requires a published flow

The chatbot must have a published conversation flow. Use the Flows API to publish one.

Create Chat Session

Creates a new conversation session. The session is created empty — the bot's greeting is returned as the response to the first message you send, exactly like the web and playground channels.

http

POST /api/dev/v1/chatbots/{chatbot_id}/chat/sessions
Authorization: Bearer <api-key>POST /api/dev/v1/chatbots/{chatbot_id}/chat/sessions
Authorization: Bearer <api-key>

bash

curl -X POST https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions \
  -H "Authorization: Bearer <your-api-key>"curl -X POST https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions \
  -H "Authorization: Bearer <your-api-key>"

Response - 201 Created

json

{
  "session_id": "01JPQ...",
  "channel": "api",
  "created_at": "2026-04-02T12:00:00Z"
}{
  "session_id": "01JPQ...",
  "channel": "api",
  "created_at": "2026-04-02T12:00:00Z"
}

To receive the bot's greeting, send the user's first message to Send Message (POST /api/dev/v1/chatbots/{chatbot_id}/chat/sessions/{session_id}/messages). The response to that first message contains the flow's welcome/greeting (the same messages a user sees when opening the chat widget), following the GenericMessage structure.

Errors:

Status	Detail
`400`	No published flow found for this chatbot
`404`	Chatbot not found

Send Message

Sends a user message and returns the bot's response synchronously.

http

POST /api/dev/v1/chatbots/{chatbot_id}/chat/sessions/{session_id}/messages
Authorization: Bearer <api-key>
Content-Type: application/jsonPOST /api/dev/v1/chatbots/{chatbot_id}/chat/sessions/{session_id}/messages
Authorization: Bearer <api-key>
Content-Type: application/json

Request Body

Fields

messagestringrequired

User message text. Max 4096 characters.

message_typestringoptionaldefault: text

"text" or "button".

button_idstring | nulloptional

The button or list item ID when the user clicks a button. When set, message_type is treated as "button" automatically.

Sending a text message

bash

curl -X POST https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions/<session-id>/messages \
  -H "Authorization: Bearer <your-api-key>" \
  -H "Content-Type: application/json" \
  -d '{"message": "I need help with my order"}'curl -X POST https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions/<session-id>/messages \
  -H "Authorization: Bearer <your-api-key>" \
  -H "Content-Type: application/json" \
  -d '{"message": "I need help with my order"}'

Sending a button click

When the bot sends buttons or a list, use the button's id field:

bash

curl -X POST https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions/<session-id>/messages \
  -H "Authorization: Bearer <your-api-key>" \
  -H "Content-Type: application/json" \
  -d '{"message": "FAQ", "button_id": "faq"}'curl -X POST https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions/<session-id>/messages \
  -H "Authorization: Bearer <your-api-key>" \
  -H "Content-Type: application/json" \
  -d '{"message": "FAQ", "button_id": "faq"}'

Response - 200 OK

json

{
  "session_id": "01JPQ...",
  "messages": [
    {
      "type": "text",
      "text": "Sure! Here are our most common questions:"
    },
    {
      "type": "list",
      "text": "Select a topic",
      "button_text": "View topics",
      "sections": [
        {
          "title": "General",
          "rows": [
            { "id": "hours", "title": "Business hours" },
            { "id": "pricing", "title": "Pricing" }
          ]
        }
      ]
    }
  ],
  "messages_count": 2,
  "current_state": "faq_menu",
  "timestamp": "2026-04-02T12:00:05Z"
}{
  "session_id": "01JPQ...",
  "messages": [
    {
      "type": "text",
      "text": "Sure! Here are our most common questions:"
    },
    {
      "type": "list",
      "text": "Select a topic",
      "button_text": "View topics",
      "sections": [
        {
          "title": "General",
          "rows": [
            { "id": "hours", "title": "Business hours" },
            { "id": "pricing", "title": "Pricing" }
          ]
        }
      ]
    }
  ],
  "messages_count": 2,
  "current_state": "faq_menu",
  "timestamp": "2026-04-02T12:00:05Z"
}

Errors:

Status	Detail
`404`	Chat session not found
`410`	Chat session has been closed
`500`	Message processing failed

Session Lifecycle

Creation: Each POST /sessions creates a new isolated conversation with its own state.
Expiry: Sessions expire after 30 minutes of inactivity (no messages sent). After expiry, the bot resets to its initial state on the next message in a new session.
Channel isolation: Chat API sessions use the api channel. They are completely isolated from the same chatbot's whatsapp, web, or sms conversations.
Conversation history: All sessions and messages are persisted and can be retrieved via the Conversations API using channel=api.

Message Format

Bot responses use the GenericMessage format - the same structure used across all channels. Each message has a type field that determines which other fields are present.

Message Types

Type	Description	Key Fields
`text`	Plain text message	`text`
`buttons`	Text with interactive buttons	`text`, `buttons[]` (each has `id`, `title`)
`list`	Sectioned list with selectable rows	`text`, `button_text`, `sections[]`
`image`	Image with optional caption	`media_url`, `media_caption`
`document`	Document file	`media_url`, `media_filename`, `media_caption`
`video`	Video file	`media_url`, `media_caption`
`audio`	Audio file	`media_url`

Example: Text message

json

{ "type": "text", "text": "Hello! How can I help?" }{ "type": "text", "text": "Hello! How can I help?" }

Example: Buttons

json

{
  "type": "buttons",
  "text": "What would you like to do?",
  "buttons": [
    { "id": "order_status", "title": "Check order" },
    { "id": "new_order", "title": "Place order" }
  ]
}{
  "type": "buttons",
  "text": "What would you like to do?",
  "buttons": [
    { "id": "order_status", "title": "Check order" },
    { "id": "new_order", "title": "Place order" }
  ]
}

Example: List

json

{
  "type": "list",
  "text": "Select a product category",
  "button_text": "View categories",
  "sections": [
    {
      "title": "Electronics",
      "rows": [
        { "id": "phones", "title": "Phones", "description": "Smartphones and accessories" },
        { "id": "laptops", "title": "Laptops" }
      ]
    }
  ]
}{
  "type": "list",
  "text": "Select a product category",
  "button_text": "View categories",
  "sections": [
    {
      "title": "Electronics",
      "rows": [
        { "id": "phones", "title": "Phones", "description": "Smartphones and accessories" },
        { "id": "laptops", "title": "Laptops" }
      ]
    }
  ]
}

Full Example

A complete conversation flow using curl:

bash

# 1. Create a session
SESSION=$(curl -s -X POST \
  https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions \
  -H "Authorization: Bearer <your-api-key>" | jq -r '.session_id')

echo "Session: $SESSION"

# 2. Send a message
curl -s -X POST \
  "https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions/$SESSION/messages" \
  -H "Authorization: Bearer <your-api-key>" \
  -H "Content-Type: application/json" \
  -d '{"message": "What are your business hours?"}' | jq

# 3. Send a follow-up
curl -s -X POST \
  "https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions/$SESSION/messages" \
  -H "Authorization: Bearer <your-api-key>" \
  -H "Content-Type: application/json" \
  -d '{"message": "Thanks!"}' | jq# 1. Create a session
SESSION=$(curl -s -X POST \
  https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions \
  -H "Authorization: Bearer <your-api-key>" | jq -r '.session_id')

echo "Session: $SESSION"

# 2. Send a message
curl -s -X POST \
  "https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions/$SESSION/messages" \
  -H "Authorization: Bearer <your-api-key>" \
  -H "Content-Type: application/json" \
  -d '{"message": "What are your business hours?"}' | jq

# 3. Send a follow-up
curl -s -X POST \
  "https://developers.sarufi.io/api/dev/v1/chatbots/<chatbot-id>/chat/sessions/$SESSION/messages" \
  -H "Authorization: Bearer <your-api-key>" \
  -H "Content-Type: application/json" \
  -d '{"message": "Thanks!"}' | jq

Python example

python

import requests

BASE = "https://developers.sarufi.io/api/dev/v1"
HEADERS = {"Authorization": "Bearer <your-api-key>"}
CHATBOT_ID = "<chatbot-id>"

# Create session (returns session_id only — no greeting yet)
resp = requests.post(f"{BASE}/chatbots/{CHATBOT_ID}/chat/sessions", headers=HEADERS)
session_id = resp.json()["session_id"]

# Send the user's first message — the response contains the greeting AND the reply.
# Do not send a warmup message first; it would consume the greeting turn.
resp = requests.post(
    f"{BASE}/chatbots/{CHATBOT_ID}/chat/sessions/{session_id}/messages",
    headers=HEADERS,
    json={"message": "Hello"},
)
print("Bot:", resp.json()["messages"])import requests

BASE = "https://developers.sarufi.io/api/dev/v1"
HEADERS = {"Authorization": "Bearer <your-api-key>"}
CHATBOT_ID = "<chatbot-id>"

# Create session (returns session_id only — no greeting yet)
resp = requests.post(f"{BASE}/chatbots/{CHATBOT_ID}/chat/sessions", headers=HEADERS)
session_id = resp.json()["session_id"]

# Send the user's first message — the response contains the greeting AND the reply.
# Do not send a warmup message first; it would consume the greeting turn.
resp = requests.post(
    f"{BASE}/chatbots/{CHATBOT_ID}/chat/sessions/{session_id}/messages",
    headers=HEADERS,
    json={"message": "Hello"},
)
print("Bot:", resp.json()["messages"])
